ETL Category-6 Indoor LAN Cable is a high-performance network deployment cable featuring 23 AWG solid conductors constructed in a 4-pair Unshielded Twisted Pair (UTP) configuration. Designed explicitly for reliable commercial and residential indoor horizontal cabling infrastructures, this cable delivers standard-compliant electrical performance for localized high-bandwidth communication networks, data centers, and structural distributions.
Applications
-
High-speed horizontal distribution cabling for indoor local area networks (LAN).
-
Interconnect lines for digital building infrastructure, office networks, and smart automation systems.
-
Seamless patching for server rooms, network racks, patch panels, and telecommunication distribution frames.
Features
-
Optimal Gauge Structure: Uses 23 AWG solid conductors ($0.56\text{ mm} \pm$) that offer an exceptional balance of tensile strength and flexible physical routing in standard interior conduits.
-
Unshielded Precision Layout: Standard UTP design minimizes physical diameter, making it easy to pull, splice, and terminate within standard RJ45 systems and patch points.
-
Value-Driven Composition: Incorporates specialized Solid CCA conductor technology to optimize electrical signaling while delivering highly competitive structural cost metrics.
-
Highly Identifiable Sheathing: Outfitted in a clean, professional blue jacket layer for rapid cable identification and trace-mapping during installation and maintenance.
#Solid #Cat6 indoor cable #23AWG ( 0.56mm+/-)
| Parameter | Specification | Notes / Compliance |
| PoE Compatibility | Standard PoE (IEEE 802.3af) | Suitable for low-wattage IP cameras / VoIP phones |
| Maximum PoE Wattage | 15.4W | Optimized for data-heavy, low-heat indoor environments |
| TIA 568-C.2 Cat6 Link | Compliant | Meets transmission protocols for Category 6 |
| Maximum Application Speed | 1000Mbps (1GBASE-T) | Supports high-speed Gigabit Ethernet networks |
| Nominal Velocity of Propagation (NVP) | 65% – 68% | Standard propagation speed for CCA cores |
| Maximum Operating Voltage | 300V | Safe rating for standard network equipment infrastructure |
| 1.0 – 250MHz Impedance ($\Omega$) | 100 ± 15 | Industry standard differential impedance |
| Maximum Operating Frequency | 250MHz | Standard Cat6 frequency bandwidth |
| 1.0 – 250MHz Delay Skew (ns/100m) | ≤ 45 | Ensures tight arrival timing across all 4 twisted pairs |
| Pair-to-Ground Capacitance Unbalance | ≤ 3300pF/km | Minimizes external signal interference and noise |
| Max. Conductor DC Resistance 20°C | ≤ 135 Ω/km | Accurate physical metric for 23 AWG CCA |
